基于spark的预测系统设计与实现 (spark逻辑回归预测分数)

🏷️ 爱音乐的程序员小新人 ✍️ 爱好音乐 Java程序开发数据库JavaWeb编程 架构J2ME程序 📅 2018-08-20 10:34:47

分类和聚类算法很多，但是对数据进行精准预测的算法不是很多，这里介绍下最常用的线性回归例子

spark官网上给出的例子不够全面，网上有些例子也不够具体，自己整理了一份

我的开发环境是ubuntu+IDEA+spark+scala

训练数据LR_data如下

  2. 3615, 3624, 2.1, 69.05, 15.1, 41.3, 20, 50708
  3. 365, 6315, 1.5, 69.31, 11.3, 66.7, 152, 566432
  4. 2212, 4530, 1.8, 70.55, 7.8, 58.1, 15, 113417
  5. 2110, 3378, 1.9, 70.66, 10.1, 39.9, 65, 51945
  6. 21198, 5114, 1.1, 71.71, 10.3, 62.6, 20, 156361
  7. 2541, 4884, 0.7, 72.06, 6.8, 63.9, 166, 103766
  8. 3100, 5348, 1.1, 72.48, 3.1, 56, 139, 4862
  9. 579, 4809, 0.9, 70.06, 6.2, 54.6, 103, 1982
  10. 8277, 4815, 1.3, 70.66, 10.7, 52.6, 11, 54090
  11. 4931, 4091, 2, 68.54, 13.9, 40.6, 60, 58073
  12. 868, 4963, 1.9, 73.6, 6.2, 61.9, 0, 6425
  13. 813, 4119, 0.6, 71.87, 5.3, 59.5, 126, 82677
  14. 11197, 5107, 0.9, 70.14, 10.3, 52.6, 127, 55748
  15. 5313, 4458, 0.7, 70.88, 7.1, 52.9, 122, 36097
  16. 2861, 4628, 0.5, 72.56, 2.3, 59, 140, 55941
  17. 2280, 4669, 0.6, 72.58, 4.5, 59.9, 114, 81787
  18. 3387, 3712, 1.6, 70.1, 10.6, 38.5, 95, 39650
  19. 3806, 3545, 2.8, 68.76, 13.2, 42.2, 12, 44930
  20. 1058, 3694, 0.7, 70.39, 2.7, 54.7, 161, 30920
  21. 4122, 5299, 0.9, 70.22, 8.5, 52.3, 101, 9891
  22. 5814, 4755, 1.1, 71.83, 3.3, 58.5, 103, 7826
  23. 9111, 4751, 0.9, 70.63, 11.1, 52.8, 125, 56817
  24. 3921, 4675, 0.6, 72.96, 2.3, 57.6, 160, 79289
  25. 2341, 3098, 2.4, 68.09, 12.5, 41, 50, 47296
  26. 4767, 4254, 0.8, 70.69, 9.3, 48.8, 108, 68995
  27. 746, 4347, 0.6, 70.56, 5, 59.2, 155, 145587
  28. 1544, 4508, 0.6, 72.6, 2.9, 59.3, 139, 76483
  29. 590, 5149, 0.5, 69.03, 11.5, 65.2, 188, 109889
  30. 812, 4281, 0.7, 71.23, 3.3, 57.6, 174, 9027
  31. 7333, 5237, 1.1, 70.93, 5.2, 52.5, 115, 7521
  32. 1144, 3601, 2.2, 70.32, 9.7, 55.2, 120, 121412
  33. 18076, 4903, 1.4, 70.55, 10.9, 52.7, 82, 47831
  34. 5441, 3875, 1.8, 69.21, 11.1, 38.5, 80, 48798
  35. 637, 5087, 0.8, 72.78, 1.4, 50.3, 186, 69273
  36. 10735, 4561, 0.8, 70.82, 7.4, 53.2, 124, 40975
  37. 2715, 3983, 1.1, 71.42, 6.4, 51.6, 82, 68782
  38. 2284, 4660, 0.6, 72.13, 4.2, 60, 44, 96184
  39. 11860, 4449, 1, 70.43, 6.1, 50.2, 126, 44966
  40. 931, 4558, 1.3, 71.9, 2.4, 46.4, 127, 1049
  41. 2816, 3635, 2.3, 67.96, 11.6, 37.8, 65, 30225
  42. 681, 4167, 0.5, 72.08, 1.7, 53.3, 172, 75955
  43. 4173, 3821, 1.7, 70.11, 11, 41.8, 70, 41328
  44. 12237, 4188, 2.2, 70.9, 12.2, 47.4, 35, 262134
  45. 1203, 4022, 0.6, 72.9, 4.5, 67.3, 137, 82096
  46. 472, 3907, 0.6, 71.64, 5.5, 57.1, 168, 9267
  47. 4981, 4701, 1.4, 70.08, 9.5, 47.8, 85, 39780
  48. 3559, 4864, 0.6, 71.72, 4.3, 63.5, 32, 66570
  49. 1799, 3617, 1.4, 69.48, 6.7, 41.6, 100, 24070
  50. 4589, 4468, 0.7, 72.48, 3, 54.5, 149, 54464
  51. 376, 4566, 0.6, 70.29, 6.9, 62.9, 173, 97203
  1. 预测数据LR_data_for_predict如下(在上面数据的基础上，对predict_target数据和第一个特征数据进行了修改，只修改了前10个记录。由于predict_target是需要预测的数据，事先不知道，但是为了保证数据格式，需要加上，这里默认为0，不影响。)
  2. 615, 3624, 2.1, 69.05, 0, 41.3, 20, 50708
  3. 65, 6315, 1.5, 69.31, 0, 66.7, 152, 566432
  4. 212, 4530, 1.8, 70.55, 0, 58.1, 15, 113417
  5. 110, 3378, 1.9, 70.66, 0, 39.9, 65, 51945
  6. 1198, 5114, 1.1, 71.71,0, 62.6, 20, 156361
  7. 541, 4884, 0.7, 72.06, 0, 63.9, 166, 103766
  8. 100, 5348, 1.1, 72.48, 0, 56, 139, 4862
  9. 79, 4809, 0.9, 70.06, 0, 54.6, 103, 1982
  10. 277, 4815, 1.3, 70.66, 0, 52.6, 11, 54090
  11. 931, 4091, 2, 68.54, 0, 40.6, 60, 58073
  12. 868, 4963, 1.9, 73.6, 6.2, 61.9, 0, 6425
  13. 813, 4119, 0.6, 71.87, 5.3, 59.5, 126, 82677
  14. 11197, 5107, 0.9, 70.14, 10.3, 52.6, 127, 55748
  15. 5313, 4458, 0.7, 70.88, 7.1, 52.9, 122, 36097
  16. 2861, 4628, 0.5, 72.56, 2.3, 59, 140, 55941
  17. 2280, 4669, 0.6, 72.58, 4.5, 59.9, 114, 81787
  18. 3387, 3712, 1.6, 70.1, 10.6, 38.5, 95, 39650
  19. 3806, 3545, 2.8, 68.76, 13.2, 42.2, 12, 44930
  20. 1058, 3694, 0.7, 70.39, 2.7, 54.7, 161, 30920
  21. 4122, 5299, 0.9, 70.22, 8.5, 52.3, 101, 9891
  22. 5814, 4755, 1.1, 71.83, 3.3, 58.5, 103, 7826
  23. 9111, 4751, 0.9, 70.63, 11.1, 52.8, 125, 56817
  24. 3921, 4675, 0.6, 72.96, 2.3, 57.6, 160, 79289
  25. 2341, 3098, 2.4, 68.09, 12.5, 41, 50, 47296
  26. 4767, 4254, 0.8, 70.69, 9.3, 48.8, 108, 68995
  27. 746, 4347, 0.6, 70.56, 5, 59.2, 155, 145587
  28. 1544, 4508, 0.6, 72.6, 2.9, 59.3, 139, 76483
  29. 590, 5149, 0.5, 69.03, 11.5, 65.2, 188, 109889
  30. 812, 4281, 0.7, 71.23, 3.3, 57.6, 174, 9027
  31. 7333, 5237, 1.1, 70.93, 5.2, 52.5, 115, 7521
  32. 1144, 3601, 2.2, 70.32, 9.7, 55.2, 120, 121412
  33. 18076, 4903, 1.4, 70.55, 10.9, 52.7, 82, 47831
  34. 5441, 3875, 1.8, 69.21, 11.1, 38.5, 80, 48798
  35. 637, 5087, 0.8, 72.78, 1.4, 50.3, 186, 69273
  36. 10735, 4561, 0.8, 70.82, 7.4, 53.2, 124, 40975
  37. 2715, 3983, 1.1, 71.42, 6.4, 51.6, 82, 68782
  38. 2284, 4660, 0.6, 72.13, 4.2, 60, 44, 96184
  39. 11860, 4449, 1, 70.43, 6.1, 50.2, 126, 44966
  40. 931, 4558, 1.3, 71.9, 2.4, 46.4, 127, 1049
  41. 2816, 3635, 2.3, 67.96, 11.6, 37.8, 65, 30225
  42. 681, 4167, 0.5, 72.08, 1.7, 53.3, 172, 75955
  43. 4173, 3821, 1.7, 70.11, 11, 41.8, 70, 41328
  44. 12237, 4188, 2.2, 70.9, 12.2, 47.4, 35, 262134
  45. 1203, 4022, 0.6, 72.9, 4.5, 67.3, 137, 82096
  46. 472, 3907, 0.6, 71.64, 5.5, 57.1, 168, 9267
  47. 4981, 4701, 1.4, 70.08, 9.5, 47.8, 85, 39780
  48. 3559, 4864, 0.6, 71.72, 4.3, 63.5, 32, 66570
  49. 1799, 3617, 1.4, 69.48, 6.7, 41.6, 100, 24070
  50. 4589, 4468, 0.7, 72.48, 3, 54.5, 149, 54464
  51. 376, 4566, 0.6, 70.29, 6.9, 62.9, 173, 97203
  1. 实现代码如下
  2. /**
  3. * Created by wangtuntun on 17-3-8.
  4. * 利用线性回归模型对数据进行回归预测
  5. */
  8. import org.apache.spark.sql.{DataFrame, SQLContext}
  9. import org.apache.spark.{SparkConf, SparkContext}
  10. import org.apache.spark.mllib.linalg.{Vector, Vectors}
  11. import org.apache.spark.ml.feature.VectorAssembler
  12. import org.apache.spark.ml.regression.LinearRegression
  13. object linnear_regression_online {
  14. def main(args: Array[String]): Unit = {
  16. //设置环境
  17. val conf=new SparkConf().setAppName("tianchi").setMaster("local")
  18. val sc=new SparkContext(conf)
  19. val sqc=new SQLContext(sc)
  21. //准备训练集合
  22. val raw_data=sc.textFile("/home/wangtuntun/LR_data")
  23. val map_data=raw_data.map{x=>
  24. val split_list=x.split(",")
  25. (split_list(0).toDouble,split_list(1).toDouble,split_list(2).toDouble,split_list(3).toDouble,split_list(4).toDouble,split_list(5).toDouble,split_list(6).toDouble,split_list(7).toDouble)
  26. }
  27. val df=sqc.createDataFrame(map_data)
  28. val data = df.toDF("Population", "Income", "Illiteracy", "LifeExp", "Murder", "HSGrad", "Frost", "Area")
  29. val colArray = Array("Population", "Income", "Illiteracy", "LifeExp", "HSGrad", "Frost", "Area")
  30. val assembler = new VectorAssembler().setInputCols(colArray).setOutputCol("features")
  31. val vecDF: DataFrame = assembler.transform(data)
  33. //准备预测集合
  34. val raw_data_predict=sc.textFile("/home/wangtuntun/LR_data_for_predict")
  35. val map_data_for_predict=raw_data_predict.map{x=>
  36. val split_list=x.split(",")
  37. (split_list(0).toDouble,split_list(1).toDouble,split_list(2).toDouble,split_list(3).toDouble,split_list(4).toDouble,split_list(5).toDouble,split_list(6).toDouble,split_list(7).toDouble)
  38. }
  39. val df_for_predict=sqc.createDataFrame(map_data_for_predict)
  40. val data_for_predict = df_for_predict.toDF("Population", "Income", "Illiteracy", "LifeExp", "Murder", "HSGrad", "Frost", "Area")
  41. val colArray_for_predict = Array("Population", "Income", "Illiteracy", "LifeExp", "HSGrad", "Frost", "Area")
  42. val assembler_for_predict = new VectorAssembler().setInputCols(colArray_for_predict).setOutputCol("features")
  43. val vecDF_for_predict: DataFrame = assembler_for_predict.transform(data_for_predict)
  45. // 建立模型，预测谋杀率Murder
  46. // 设置线性回归参数
  47. val lr1 = new LinearRegression()
  48. val lr2 = lr1.setFeaturesCol("features").setLabelCol("Murder").setFitIntercept(true)
  49. // RegParam：正则化
  50. val lr3 = lr2.setMaxIter(10).setRegParam(0.3).setElasticNetParam(0.8)
  51. val lr = lr3
  53. // 将训练集合代入模型进行训练
  54. val lrModel = lr.fit(vecDF)
  56. // 输出模型全部参数
  57. lrModel.extractParamMap()
  58. // Print the coefficients and intercept for linear regression
  59. println(s"Coefficients: ${lrModel.coefficients} Intercept: ${lrModel.intercept}")
  61. // 模型进行评价
  62. val trainingSummary = lrModel.summary
  63. println(s"numIterations: ${trainingSummary.totalIterations}")
  64. println(s"objectiveHistory: ${trainingSummary.objectiveHistory.toList}")
  65. trainingSummary.residuals.show()
  66. println(s"RMSE: ${trainingSummary.rootMeanSquaredError}")
  67. println(s"r2: ${trainingSummary.r2}")
  70. val predictions: DataFrame = lrModel.transform(vecDF_for_predict)
  71. // val predictions = lrModel.transform(vecDF)
  72. println("输出预测结果")
  73. val predict_result: DataFrame =predictions.selectExpr("features","Murder", "round(prediction,1) as prediction")
  74. predict_result.foreach(println(_))
  75. sc.stop()
  76. }
  77. }
